Question 1

A node is a member of various pools and hosts different web applications. If a web application is unavailable, the BIG-IP appliance needs to mark the pool member down for that application pool. What should a BIG-IP Administrator deploy at the pool level to accomplish this?

Options :

A : A UDP monitor with a custom interval/timeout

B : A combination of ICMP + TCP monitor

C : An HTTP monitor with custom send/receive strings

D : A TCP monitor with a custom interval/timeout

Answer: C

Question 2

Refer to the exhibit.

Other-Image-2c06da883-f0d5-4292-801f-66668a9561f2

How many nodes are represented on the network map shown?

Options :

A : Four

B : Three

C : One

D : Two

Answer: B

Question 3

Which type of Virtual Server requires the use of a FastL4 profile?

Options :

A : Performance (Layer 4)

B : Stateless

C : Performance (HTTP)

D : Standard

Answer: A

Question 4

A standard virtual server has been associated with a pool with multiple members. Assuming all other settings are left at their defaults, which statement is always true concerning traffic processed by the virtual server?

Options :

A :

The client IP address is unchanged between the client side connection and the serverside connection.

B :

The server IP address is unchanged between the client side connection and the serverside connection.

C :

The TCP ports used in the client side connection are the same as the TCP ports serverside connection.

D :

The IP addresses used in the clientside connection are the same as the IP addresses used in the serverside connection.

Answer: A

Question 5

A 8IG-IP device is replaced with an RMA device. The BIG-IP Administrator renews the license and tries to restore the configuration from a previously generated UCS archive on the RMA device. The device configuration is NOT fully loading. What is causing the configuration load to fail?

Options :

A : The Device Group is NOT configured for Full Sync.

B : The US does NOT contain the full config

C : The clock is NOT set correctly

D : The Master Key is NOT restored

Answer: D
