Question 1

An engineer must optimize ARP responses and reduce unnecessary ARP broadcasts over the VXLAN/EVPN fabric. Which action accomplishes these tasks?

Options :

A : Configure ip proxy-arp under the VLAN SVI associated with the VXLAN VNI.

B : Configure ip proxy-arp within the VXLAN VNI configuration under the VTEP NVE interface.

C : Configure suppress-arp within the VXLAN VNI configuration under the VTEP NVE interface.

D : Configure suppress-arp under the VLAN SVI associated with the VXLAN VNI.

Answer: C

Question 2

Refer to the exhibit. A source is sending a multicast traffic stream to the receiver. How is the multicast traffic expected to flow through the network when it reaches a vPC peer?

Options :

A :

The multicast traffic is not replicated to the ports that joined a multicast group (224.0.0.13) or the peer link The multicast traffic stream flows over the vPC link to ensure that orphan ports get the multicast stream in failure scenarios.

B :

The multicast traffic is replicated to the ports that joined a given multicast group and the peer link. The multicast traffic stream flows from Agg-1 to Agg-2 over the M1-to-M2 peer link and forwards the traffic over Layer 4 to Access-2.

C :

The multicast traffic is replicated to the ports that joined a given multicast group and the peer link. The multicast traffic stream flows over the peer link to ensure that orphan ports receive the multicast stream in failure scenarios

D :

The multicast traffic is not replicated to the ports that joined a multicast group (224.0.0.13) or the peer link. The multicast traffic stream flows from Agg-1 to Agg-2 over the M1-to-M2 peer link and forwards the traffic over Layer 4 to Access-2.

Answer: D

Question 3

An engineer is using REST API calls to configure the cisco APIC. Which data structure must be used within a post message to receive a login token?

Options :

A : {"aaaUser":{"attributes":{"name":"apiuser","pwd":"cisco123"}}}

B :

C : {aaaUser:{attributes:{name:apiuser,pwd:cisco123}}}

D : apiusercisco123

Answer: A

Question 4

A network engineer is configuring the Cisco UCS service profile template with Ansible using this code.

Which attribute must be used to apply the iSCSI initiator identifiers to all iSCSI vNICs for the service profiles derived from the service template?

Options :

A : san_connectivity_policy

B : iqn_pool

C : boot_policy

D : lan_connectivrty_policy

Answer: B

Question 5

Refer to the exhibit.

What is the result of implementing this configuration?

Options :

A : The TACACS+ server uses the type-6 encrypted format.

B : The switch queries the TACACS+ server by using a clear text PAP login.

C : The timeout value on the TACACS+ server is 10 seconds.

D : The switch queries the TACACS+ server by using an encrypted text PAP login.

Answer: D
